| GENERAL DESCRIPTION |
 |
The 6961 / TBL7/8000 is a forced air-cooled triode designed for use in industrial RF generators and communication transmitters. The 6961 / TBL7/8000 features an exclusive specially processed grid which makes possible its high grid current rating and overload characteristics. This is particularly desirable in heavy-duty, industrial applications. The filament is thoriated tungsten. Maximum ratings apply up to 30 megacycles. |
| TECHNICAL SPECIFICATIONS | |
| ELECTRICAL | |
| Filament Voltage Current |
Thoriated tungsten 12.6 volts 33 amps |
| Amplification Factor | 32 |
| Transconductance | 15,000 μmhos |
| Direct Interelectrode Capacitances Grid to Plate Grid to Filament Plate to Filament |
11 μμf 16 μμf 0.3 μμf |
| MECHANICAL | |
| Mounting Position | Vertical with anode up or down |
| Cooling | Forced air |
| Temperature of filament seals | max. 210 °C |
| Temperature of grid and anode seals | max. 180 °C |
| Net weight | 4,6 kg |
| Specifications may change without notice | |
| THIS TUBE IS USED IN THE FOLLOWING SHORTWAVE BROADCAST TRANSMITTERS | ||
| Manufacturer | Transmitter specifications | Power in kW |
| Philips | 8FZ 510 | 25 |
| 8FZ 513 | 25 | |
| THIS TUBE IS AVAILABLE FROM | ||
| Manufacturer | Rebuilder | Distributor |
| Kennetron | Richardson Electronics | |
| PRICE LEVEL (US$) | |||||
| 1 | 2 | 3 | 4 | 5 | 6 |
| 0 - 10 | 10 - 100 | 100 - 1000 | 1000 - 10,000 | 10,000 - 50,000 | 50,000 - 100,000 |
